Ghidra Reverse Engineering—REBEXE.EXE¶
Exhaustive decompilation of Star Wars Rebellion (1998, LucasArts) for the Open Rebellion reimplementation.
What We Decompiled¶
| Target | Size | Total Functions | Decompiled | Coverage |
|---|---|---|---|---|
| REBEXE.EXE | 2.8 MB | 22,741 | 5,127 | Every function >100 bytes |
| COMMON.DLL | 2.9 MB | 0 | 0 | Resource container (321 BMPs, 5 WAVs). No game logic. |
| STRATEGY.DLL | 29 MB | 43 (CRT only) | N/A | Resource-only—no game logic |
Key finding: All game logic lives in REBEXE.EXE. STRATEGY.DLL and COMMON.DLL are resource containers only (BMPs, strings, data tables). DirectPlay networking lives in REBEXE.EXE at 0x5a0000–0x5b0000.
Scholar Documents (7 analysis docs, 6,049 lines)¶
| Document | Lines | What It Covers |
|---|---|---|
notes/annotated-functions.md |
1,662 | Struct field layouts (+0x60 hull, +0x64 shield nibbles, +0x96 regiment strength, +0xac alive flag), renamed variables, 50 event IDs (0x127–0x370), game rules |
notes/modders-taxonomy.md |
805 | 10 game systems mapped for total conversion mods (Yuuzhan Vong, Thrawn's Revenge, KOTOR). Per-system function addresses, GNPRTB parameters, mod guidance |
notes/rust-implementation-guide.md |
1,267 | Maps decompiled C to Open Rebellion's stateless advance() pattern. CombatSystem::resolve_space(), GnprtbParams, MstbTable, 15 missing CapitalShipClass fields |
notes/cpp-class-hierarchy.md |
445 | CRebObject → CNotifyObject → CCombatUnit hierarchy. 19 vtable slots, 6 vtable pointer constants, field layouts, setter-notify-event pattern |
notes/entity-system.md |
668 | Characters (8 enhanced skills, Force/Jedi 6-tier, betrayal), game objects (5 destruction variants), fleets (4 events), factions (Alliance/Empire/Neutral bit encoding) |
notes/mission-event-cookbook.md |
724 | 9+ mission types (FUN_0050d5a0 13-case switch), 4 story event chains (Dagobah, Vader's Palace, Bounty Hunters, Jabba), event ID registry |
notes/economy-systems.md |
478 | Resources (energy/material at +0x5c–0x68), 5 ControlKind states, uprising tables (UPRIS1TB/2TB), blockade manufacturing halt, repair formulas |
Combat Subsystem (3 dedicated docs)¶
| Document | Subsystem | Key Functions |
|---|---|---|
notes/space-combat.md |
Space combat—7-phase auto-resolve pipeline | FUN_00549910, FUN_00544030, FUN_005443f0 |
notes/ground-combat.md |
Ground combat—troop iteration + per-unit resolution | FUN_00560d50, FUN_004ee350, FUN_005617b0 |
notes/bombardment.md |
Orbital bombardment—Euclidean distance formula | FUN_00556430, FUN_0055d8c0, FUN_0055d860 |
AI Pipeline (6 core functions fully traced)¶
| # | Function | Purpose | Lines | Status in Open Rebellion |
|---|---|---|---|---|
| 1 | FUN_00519d00 | Galaxy-wide system bucketing (7 categories) | 252 | DONE—evaluate_galaxy_state() + ratio scoring |
| 2 | FUN_00537180 | Primary fleet deployment (per-system iteration) | 381 | AUGMENTED—per-fleet scoring with 4 factors |
| 3 | FUN_005385f0 | Secondary deployment (redistribution) | 252 | DONE—aggression-scaled redistribution |
| 4 | FUN_00502020 | Garrison strength assessment | 897 | DONE—ships + troops + facilities |
| 5 | FUN_00508250 | Pre-dispatch validation (18 boolean checks) | ~200 | DONE—can_dispatch() with 6 checks |
| 6 | FUN_00520580 | Movement order issuance | ~300 | DONE—with already_moving dedup |
Key Discoveries¶
- 111 GNPRTB parameters mapped: 34 general (28 base + 6 per-side) + 77 combat (25 base + 52 per-side). These are the "knobs" that control game difficulty and balance.
- Bombardment formula:
damage = sqrt((atk[0]-def[0])^2 + (atk[1]-def[1])^2) / GNPRTB[0x1400] - Hull and squad_size share offset +0x60—polymorphism by vtable, not separate structs
- Shield/weapon recharge packed into 4-bit nibbles at offset +0x64
- C++ class hierarchy: CRebObject → CNotifyObject → CCombatUnit/CCharacter/CStarSystem—all combat dispatched via vtable
- AI is omniscient—no fog-of-war check in FUN_00519d00 (galaxy evaluation)
- Turn processing: FUN_004927c0 (9K lines) is the master tick function—research dispatch, fleet orders, manufacturing, event processing
Ghidra Scripts (8 Jython scripts)¶
| Script | Purpose |
|---|---|
FindAllFunctions.py |
x86 prologue scanner—finds all function entry points |
DumpAllGameFunctions.py |
Exhaustive catalog of 4,938 functions with referenced strings |
DumpStrings.py |
Keyword string search → file output |
DumpCombatXrefs.py |
String → function cross-reference tracer |
DumpCallers.py |
Direct caller finder for a target function |
DumpCombatRegion.py |
Function listing in combat address range |
FindCombatMath.py |
Pattern search for combat math operations |
DumpGNPRTBXrefs.py |
GNPRTB parameter → function tracer |
Decompiled Functions by Game System¶
| System | Address Range | Functions | Key Entry Points |
|---|---|---|---|
| Game init / CRT | 0x401000–0x403e90 | ~100 | entry, __security_init_cookie |
| Galaxy map (GDI) | 0x422000–0x43a000 | ~50 | FUN_00422ce0 (11K), FUN_00433e40 (6K) |
| UI dialogs | 0x43a000–0x470000 | ~200 | FUN_0044c630 (6K), FUN_004665f0 (6K) |
| Turn processing | 0x490000–0x4a0000 | ~50 | FUN_004927c0 (9K master tick) |
| Characters | 0x4ee000–0x4f4000 | ~80 | Enhanced skills, Force system, loyalty |
| Missions | 0x4f4000–0x515000 | ~120 | FUN_0050d5a0 (13-case switch) |
| AI system | 0x515000–0x540000 | ~150 | 6-function pipeline (see table above) |
| Space combat | 0x540000–0x560000 | ~100 | 7-phase pipeline, CombatPhaseFlags |
| Ground combat | 0x560000–0x570000 | ~40 | Troop iteration, regiment damage |
| Economy | 0x570000–0x590000 | ~60 | Manufacturing, resources, blockade |
| Events | 0x590000–0x5a0000 | ~40 | Scripted chains, condition/action eval |
| DirectPlay (net) | 0x5a0000–0x5b0000 | ~30 | Session management, peer-to-peer |
| MSVC runtime | 0x5b0000+ | ~4,000 | CRT, STL, exception handling |
Directory Structure¶
ghidra/
├── README.md ← you are here
├── INDEX.md # Detailed project index
├── Open Rebellion Ghidra.gpr # Ghidra project file (not tracked)
├── Open Rebellion Ghidra.rep/ # Ghidra project data (not tracked)
├── notes/
│ ├── INDEX.md # Master index of all notes
│ ├── FUNCTION_INDEX.md # 5,127-function catalog
│ ├── 7 analysis .md files # Scholar documents (see table above)
│ ├── 3 combat .md files # Combat subsystem docs
│ ├── 4 review .md files # Internal review notes
│ └── ~5,127 .c files # Decompiled C pseudocode
└── scripts/
└── 8 .py files # Ghidra Jython scripts
How to Use¶
- Open Ghidra:
ghidra(alias) - Open project:
Open Rebellion Ghidra.gpr - Double-click REBEXE.EXE in Program Trees
- Navigate to function: Go → Address →
0x00519d00 - GhidraMCP plugin (LaurieWired v11.3.2):
curl -X POST http://127.0.0.1:8080/decompile -d "FUN_ADDR" - Jython scripts: Window → Jython →
exec(open("path/to/script.py").read())
Frequently Asked Questions¶
What is REBEXE.EXE?
REBEXE.EXE is the 2.8 MB main executable of Star Wars Rebellion (1998, LucasArts). All game logic—combat, AI, diplomacy, research, events—lives in this binary. STRATEGY.DLL is a resource container only (BMPs, strings, data tables). COMMON.DLL is a pure resource container (321 BMPs: UI buttons, panel chrome, main menu backgrounds, cockpit speed-control buttons; 5 WAVs: UI interaction sounds). DirectPlay networking lives in REBEXE.EXE itself at 0x5a0000–0x5b0000.
How many functions were decompiled? 5,127 functions—every function >100 bytes—out of 22,741 total identified in REBEXE.EXE. Coverage focuses on game logic: combat, AI deployment, movement, economy, events, and mission systems.
What is the GNPRTB table? GNPRTB is a 111-parameter lookup table embedded in REBEXE.EXE that governs all combat math: damage formulas, accuracy, repair rates, and balance scaling. Parameter 0x1400 specifically controls orbital bombardment damage. The table has 34 general parameters (28 base + 6 per-side) and 77 combat parameters (25 base + 52 per-side).
How does space combat work? Space combat resolves through a 7-phase pipeline. Phase 1 loads GNPRTB parameters. Phases 2-6 compute fleet power ratios, apply modifiers, iterate unit-by-unit damage, and resolve outcomes. Phase 7 writes results. The entry point is FUN_00549910; the main resolution loop is FUN_00544030.
Is the AI tick-based or event-driven? Event-driven. Message 0x1f0 (day tick notification) triggers AI evaluation once per game-day via the CNotifyObject observer pattern. There is no fixed tick interval—the master turn function FUN_004927c0 (9,000 lines) processes all AI logic each day.
Can I use this for modding? Yes. The Modders Taxonomy document maps all 10 game systems to specific function addresses and GNPRTB parameters with guidance for total conversion mods. The GNPRTB table is the primary lever for rebalancing combat, and all mission probability formulas are documented with their MSTB table inputs.
Relationship to Open Rebellion¶
The decompiled code is the ground truth for the reimplementation. Every simulation system in crates/rebellion-core/src/ is ported from specific decompiled functions. The agent_docs/systems/ai-parity-tracker.md maps each original function to our Rust implementation with DONE/AUGMENTED/PARTIAL/MISSING status.
The ghidra/ directory is gitignored (binary project files + non-redistributable decompiled code). This README is the only tracked file. The tracked reference for agents is agent_docs/ghidra-re.md.
